TDA8510J - 26 W BTL and 2 x 13 W SE power amplifiers

Product Overview

NXP

TDA8510J 26 W BTL and 2 x 13 W SE power amplifiers by NXP - Datasheet Preview — Datasheet preview – TDA8510J

Datasheet Details

Part number	TDA8510J
Manufacturer	NXP
File Size	82.88 KB
Description	26 W BTL and 2 x 13 W SE power amplifiers
Datasheet	TDA8510J Datasheet
Additional preview pages of the TDA8510J datasheet.

Product details

Description

The TDA8510J is an integrated class-B output amplifier in a 17-lead single-in-line (SIL) power package. 100 V A mA µA W dB µV kΩ mV 150 Single-ended channels output power W W dB µV kΩ ORDERING INFORMATION TYPE NUMBER TDA8510J PACKAGE NAME DESCRIPTION VERSION

Features

Requires very few external components.
High output power.
Low output offset voltage (BTL channel).
Fixed gain.
Diagnostic facility (distortion, short-circuit and temperature detection).
Good ripple rejection.
Mode select switch (operating, mute and standby).
AC and DC short-circuit safe to ground and to VP.
Low power dissipation in any short-circuit condition.
Thermally protected.
Reverse polarity.
