TEA1099 Datasheet, Speech/handsfree, NXP

TEA1099 Features

• Speech/handsfree Line interface
• Low DC line voltage
• Voltage regulator with adjustable DC voltage
• Symmetrical high impedance inputs (70 kΩ) for dynamic, magnetic or electret

PDF File Details

Part number:

TEA1099

Manufacturer:

NXP ↗

File Size:

185.71kb

Download:

📄 Datasheet

Description:

Speech/handsfree. The TEA1099H is an analog bipolar circuit dedicated for telephone applications. It includes a line interface, handset (HS) microphone

TEA1099 Application

• Applications
• Line powered telephone sets
• Cordless telephones
• Fax machines
• Answering machines. GENERAL DESCRI
