54LVX3384

10-Bit Low Power Bus Switch

54LVX3384 Datasheet (120.47 KB)

Preview of 54LVX3384 PDF Datasheet

Datasheet Details

Part number:

54LVX3384

Manufacturer:

National Semiconductor

File Size:

120.47 KB

Description:

10-bit low power bus switch

54LVX3384 Features

* n n n n n n n 4Ω switch connection between two ports Minimal propagation delay through the switch Ultra low power with < 0.1 µA typical ICC Zero ground bounce in flow-through mode Control inputs compatible with TTL levels Available in CDIP and Cerpack Packaging Standard Microcircuit Drawing (SMD) 59

54LVX3384 General Description

The 54LVX3384 provides 10 bits of high-speed CMOS TTL-compatible bus switches. The low on resistance of the switch allows inputs to be connected to outputs without adding propagation delay or generating additional ground bounce noise. The device is organized as two 5-bit switches with separate bus e.
