AM2009 - six channel MOS multiplex switches

AM2009 Description

a AM2009/AM2009C, MM4504/MM5504 6-Channel MOS Multiplex Switches General .
The AM2009/AM2009C/MM4504/MM5504 are six channel multiplex switches constructed on a single silicon chip using low threshold P-channel MOS process.

AM2009 Applications

* such as time division multiplexing of analog or digital signals. Switching speeds are primarly determined by conditions external to the device such as signal source impedance, capacitive loading and the total number of channels used in parallel. The AM2009/MM4504 are specified for operation over the

📥 Download Datasheet

Preview of AM2009 PDF
datasheet Preview Page 2

Datasheet Details

Part number
AM2009
Manufacturer
National Semiconductor
File Size
49.01 KB
Datasheet
AM2009-NationalSemiconductor.pdf
Description
six channel MOS multiplex switches
