LM3352 - Regulated 200 mA Buck-Boost Switched Capacitor DC/DC Converter

Product Overview

National Semiconductor

Datasheet Details

Part number	LM3352
Manufacturer	National Semiconductor
File Size	516.42 KB
Description	Regulated 200 mA Buck-Boost Switched Capacitor DC/DC Converter
Datasheet	LM3352 Datasheet
Note	This datasheet PDF includes multiple part numbers: LM3352, LM3. Please refer to the document for exact specifications by model.
Additional preview pages of the LM3352 datasheet.

Product details

Description

The LM3352 is a CMOS switched capacitor DC/DC converter that produces a regulated output voltage by automatically stepping up (boost) or stepping down (buck) the input voltage.

Features

n Regulated VOUT with ± 3% accuracy n Standard output voltage options: 2.5V, 3.0V and 3.3V Typical Operating Circuit DS101037-1 © 1999 National Semiconductor Corporation DS101037 www. national. com Connection Diagram DS101037-2 Top View TSSOP-16 Pin Package See NS Package Number MTC16 Ordering Information Order Number LM3352MTCX-2.5 LM3352MTC-2.5 LM3352MTCX-3.0 LM3352MTC-3.0 LM3352MTCX-3.3 LM3352MTC-3.3 Package Type TSSOP-16 TSSOP-16 TSSOP-16 TSSOP-16 TSSOP-16 TSSOP-16 NSC Package Drawing.
