LMX1511 1.1 GHz Frequency Synthesizer

The LMX1501A and the LMX1511 are high performance frequency synthesizers with integrated prescalers designed for RF operation up to 1 1 GHz They are fabricated using National’s ABiC IV BiCMOS process The LMX1501A and the LMX1511 contain dual modulus prescalers which can select either a 64 65 or a 12.

LMX1511 Features

* Y Y Y Y Y Y RF operation up to 1 1 GHz 2 7V to 5 5V operation Low current consumption ICC e 6 mA (typ) at VCC e 3V Dual modulus prescaler 64 65 or 128 129 Internal balanced low leakage charge pump Small-outline plastic surface mount JEDEC 0 150 wide (1501A) or TSSOP 0 173 wide (1511) package Appl
