NJU6539 Datasheet, Driver, New Japan Radio

NJU6539 Features

• Driver Direct Correspondence between Display Data RAM and LCD Pixel Display Data RAM : 650-bits LCD Drivers : 65-seg, 10-com Serial interface (SIO, SCL, CS) Programmable Duty Ratio 1/8 Duty, 1

PDF File Details

Part number:

NJU6539

Manufacturer:

New Japan Radio

File Size:

82.86kb

Download:

📄 Datasheet

Description:

Bitmap lcd driver. PACKAGE OUTLINE The NJU6539 is a 10-common x 65-segment bitmap LCD driver to display graphics or characters. It contains 650 bits d
