MC74HC04A Datasheet, Inverter, ON Semiconductor

MC74HC04A Features

• Inverter
• Output Drive Capability: 10 LSTTL Loads
• Outputs Directly Interface to CMOS, NMOS and TTL
• Operating Voltage Range: 2.0 to 6.0 V (HC), 4.5 to 5.5 V (HCT)

PDF File Details

Part number:

MC74HC04A

Manufacturer:

ON Semiconductor ↗

File Size:

275.67kb

Download:

📄 Datasheet

Description:

Hex inverter.

MC74HC04A Application

• Applications Requiring Unique Site and Control Change Requirements; AEC
• Q100 Qualified and PPAP Capable
• These Devices are Pb
<
