MC74LVX14 - Hex Schmitt Inverter

ON Semiconductor

The MC74LVX14 by ON Semiconductor is a Hex Schmitt Inverter. Below is the official datasheet preview.

📥 Download Datasheet

MC74LVX14 Hex Schmitt Inverter by ON Semiconductor - Datasheet Preview — Official preview page of the MC74LVX14 Hex Schmitt Inverter datasheet (ON Semiconductor).

Datasheet Details

Part number	MC74LVX14
Manufacturer	ON Semiconductor
File Size	246.43 KB
Description	Hex Schmitt Inverter
Datasheet	MC74LVX14_ONSemiconductor.pdf
Additional preview pages of the MC74LVX14 datasheet.

MC74LVX14 Product details

Features

High Speed: tPD = 6.8 ns (Typ) at VCC = 3.3 V.
Low Power Dissipation: ICC = 2 mA (Max) at TA = 25°C.
Powerdown Protection Provided on Inputs.
Balanced Propagation Delays.
Low Noise: VOLP = 0.5 V (Max).
Pin and Function Compatible with Other Standard Logic Families.
Latchup Performance Exceeds 300 mA.
ESD Performance: Human Body Model > 2000 V; Machine Model > 200 V.
NLV Prefix for Automotive and Other.
