NCP382 - Fixed Current-Limiting Power-Distribution Switches

ON Semiconductor

NCP382 Datasheet Preview — Preview of NCP382 PDF

Datasheet Details

Part number	NCP382
Manufacturer	ON Semiconductor ↗
File Size	307.05 KB
Description	Fixed Current-Limiting Power-Distribution Switches
Datasheet	NCP382-ONSemiconductor.pdf

NCP382 Product details

Description

Pin Name Type Description EN1 I Enable 1 input, logic low/high (i.e.EN or EN) turns on power switch.EN2 I Enable 2 input, logic low/high (i.e.EN or EN) turns on power switch.GND P Ground connection.IN P Power switch input voltage; connect a 1 mF or greater ceramic capacitor from IN to GND as close as possible to the IC.FLAG1 O Active low open drain output 1, asserted during overcurrent or overtemperature conditions.

Features

2.5 V.
5.5 V Operating Range.
80 mW High.
Side MOSFET.
Current Limit: Fixed 500 mA, 1 A and 1.5 A.
Undervoltage Lock.
Out (UVLO).
Soft.
Start Prevents Inrush Current.
Thermal Protection.
Soft Turn.
Off.
Enable Active High or Low (EN or EN).
Compliance to IEC61000.
4.
2 (Level 4).
8.0 kV (Contact).
15 kV (Air).
UL Listed for SOIC package (.
