NXH004P120M3F2PTNG SiC

NXH004P120M3F2PTNG Description

Silicon Carbide (SiC) Module * EliteSiC, 4 mohm SiC M3 MOSFET, 1200 V, 2-PACK Half Bridge Topology, F2 Package with Si3N4 DBC NXH004P120M3F2PT.
for pin names ORDERING INFORMATION See detailed ordering and shipping information on page 4 of this data sheet.

NXH004P120M3F2PTNG Features

* 4 mW / 1200 V M3S SiC MOSFET Half
* Bridge
* Si3N4 DBC
* Thermistor
* Pre
* Applied Thermal Interface Material (TIM)
* Press
* Fit Pins
* These Devices are Pb

NXH004P120M3F2PTNG Applications

* Solar Inverter
* Uninterruptible Power Supplies
* Electric Vehicle Charging Stations
* Industrial Power DATA SHEET www. onsemi. com PACKAGE PICTURE PIM36 56.7x42.5 (PRESS FIT) CASE 180BY MARKING DIAGRAM NXH004P120M3F2PTNG ATYYWW NXH004P120M3F2PTNG = Specific Devi
