OR-1009 Datasheet, diode, Orient

OR-1009 Features

• Diode (1) Current transfer ratio：(CTR: 50~600% at IF = 5mA, VCE = 5V) (CTR: 63~320% at IF = 10mA, VCE = 5V) (2) High input-output isolation voltage ( Viso = 5,000Vrms ) (3) High collector-emi

PDF File Details

Part number:

OR-1009

Manufacturer:

Orient

File Size:

817.97kb

Download:

📄 Datasheet

Description:

Infrared emitting diode. The OR-10XX series devices consist of an infrared emitting diode, optically coupled to a photo transistor detector.They are packaged

OR-1009 Application

• Applications (1) Programmable controllers (2) System appliances, measuring instruments (3) Telecommunication equipments (4) Home appliances, such as
