EPA073HL Datasheet - PCA Electronics

EPA073HL 14 Pin Dip And SMD 5 Taplow-profile TTL Compatible Active Delay Lines

14 Pin DIP and SMD 5 Tap Low-Profile TTL Compatible Active Delay Lines Compatible with standard auto-insertable equipment and can be used in either infrared or vapor phase process. Delays are ±5% or ±2 nS† Total Tap 5, 10, 15, 20 6, 12, 18, 24 7, 14, 21, 28 8, 16, 24, 32 9, 18, 27, 36 10, 20, 30, 40 12, 24, 36, 48 15, 30, 45, 60 20, 40, 60, 80 25, 50, 75, 100 30, 60, 90, 120 35, 70, 105, 140 †Whichever is greater. 25 30 35 40 45 50 60 75 100 125 150 175 DIP Part Number EP8200-HL EP8213-HL EP82.

EPA073HL_PCAElectronics.pdf

Preview of EPA073HL PDF

Datasheet Details

Part number:

EPA073HL

Manufacturer:

PCA Electronics

File Size:

47.80 KB

Description:

14 pin dip and smd 5 taplow-profile ttl compatible active delay lines.
