PT2501 - 3-Phase Sinusoidal BLDC Motor Controller

Product Overview

PTC

📥 Download Datasheet

PT2501 3-Phase Sinusoidal BLDC Motor Controller by PTC - Datasheet Preview — Datasheet preview – PT2501

Datasheet Details

Part number	PT2501
Manufacturer	PTC
File Size	420.35 KB
Description	3-Phase Sinusoidal BLDC Motor Controller
Datasheet	PT2501 Datasheet
Additional preview pages of the PT2501 datasheet.

Product details

Description

The PT2501 is a three-phase, hall sensor sinusoidal brushless DC motor control chip.

Features

Hall sensor sinusoidal control for 3-phase BLDC.
Current limit function.
Over temperature protection from external NTC.
Motor lock protection.
Reverse function.
PWM or DC input for speed control.
FG output for rotation speed.
Pre-driver for 12V to 24V high side PMOS and low side NMOS.
Support Hall element and Hall sensor.
I2C interface for parameter setting and write to interal OTP.
