SB4060PT, SB4040PT - (SB4020PT - SB4060PT) Isolation Schottky Barrier Rectifiers

Pan Jit International

📥 Download Datasheet

SB4060PT Datasheet Preview — This datasheet PDF includes multiple part numbers: SB4060PT, SB4040PT. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

Datasheet Details

Part number	SB4060PT, SB4040PT
Manufacturer	Pan Jit International
File Size	181.72 KB
Description	(SB4020PT - SB4060PT) Isolation Schottky Barrier Rectifiers
Datasheet	SB4040PT_PanJitInternational.pdf
Note	This datasheet PDF includes multiple part numbers: SB4060PT, SB4040PT. Please refer to the document for exact specifications by model.

SB4060PT Product details

Features

Plastic package has Underwriters Laboratory Flammability Classification 94V-O. Flame Retardant Epoxy Molding Compound.
Exceeds environmental standards of MIL-S-19500/228.
Low power loss, high efficiency.
Low forwrd voltge, high current capability.
For use in low voltage,high frequency inverters free wheeling , and polarlity protection.
