AN3296 - Synchronous Separation/AFC

Product Overview

Panasonic Semiconductor

📥 Download Datasheet

AN3296 Synchronous Separation/AFC by Panasonic Semiconductor - Datasheet Preview — Datasheet preview – AN3296

Datasheet Details

Part number	AN3296
Manufacturer	Panasonic Semiconductor
File Size	31.68 KB
Description	Synchronous Separation/AFC
Datasheet	AN3296 Datasheet
Additional preview pages of the AN3296 datasheet.

Product details

Features

Built-in horizontal and vertical sync. signal separator and generator.
Adjustment-free horizontal AFC free-running frequency.
Built-in sync. signal detector. 21.7±0.3 AN3296 1 2 3 4 5 6 7 8 6.2±0.3 Unit : mm 1.22±0.25 0.5±0.1 16 15 14 13 12 11 10 9 4.7±0.25 1.1±0.25 3.05±0.25 2.54 0.3 + 0.1.
0.05 3˚ to 15˚ 7.62±0.25 16-Pin Plastic Package (DIP016-P-0300B) AN3296S Unit : mm 1.27 0.4±0.25 0.4 10.1±0.3 1 16 2 15 3 14 4 13 5 12 6 11 7 10 89 0.1.
