INN2025 Off-Line CV/CC Flyback Switcher IC

InnoSwitch-CH Family Off-Line CV/CC Flyback Switcher IC with Integrated 650 V MOSFET, Synchronous Rectification and Feedback Product Highlights Highly Integrated, Compact Footprint Incorporates flyback controller, 650 V MOSFET, secondary-side sensing and synchronous rectification driver Integrated FluxLink™, HIPOT-isolated, feedback link Exceptional CV/CC accuracy, independent of transformer design or external components Instantaneous transient res.

INN2025 Features

* Primary sensed output OVP

* Secondary sensed output overshoot clamp

* Secondary sensed output OCP to zero output voltage

* Hysteretic thermal shutdown Full Safety and Regulatory Compliance

* 100% production HIPOT compliance test

INN2003-PowerIntegrations.pdf

INN2025 Datasheet Preview — This datasheet PDF includes multiple part numbers: INN2025, INN2003. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

INN2025, INN2003

Manufacturer:

Power Integrations

File Size:

2.32 MB

Description:

Off-line cv/cc flyback switcher ic.

Note:

This datasheet PDF includes multiple part numbers: INN2025, INN2003.
Please refer to the document for exact specifications by model.
