TNY264GN Datasheet, Switcher, Power Integrations

TNY264GN Features

• Switcher Reduce System Cost
• Fully integrated auto-restart for short circuit and open loop fault protection
    – saves external component costs
• Built-in circuitry

PDF File Details

Part number:

TNY264GN

Manufacturer:

Power Integrations

File Size:

568.30kb

Download:

📄 Datasheet

Description:

Low power off-line switcher. TinySwitch™-II integrates a 700 V power MOSFET, oscillator, high voltage switched current source, current limit and thermal shutdown

TNY264GN Application

• Applications High Performance at Low Cost
• High voltage powered
    – ideal for charger applications
• High bandwidth p
