HYB39S128160FE - 128-MBit Synchronous DRAM

Datasheet Summary

Description

The HY[B/I]39S128[40/80/16][0/7]F[E/T](L) are four bank Synchronous DRAM’s organized as 32 MBit x4, 16 MBit x8 and 8 Mbit x16 respectively.

Features

  • Data Mask for Read / Write control (x4, x8) Data Mask for Byte Control (x16) Auto Refresh (CBR) and Self Refresh Power Down and Clock Suspend Mode 4096 refresh cycles / 64 ms (15.6 μs) Random Column Address every CLK (1-N Rule) Single 3.3 V ± 0.3 V Power Supply LVTTL Interface Plastic Packages: P(G).
  • TSOPII.
  • 54 400 mil width This chapter lists all main features of the product family HY[B/I]39.

📥 Download Datasheet

Datasheet preview – HYB39S128160FE

Datasheet Details

Part number HYB39S128160FE
Manufacturer Qimonda
File Size 1.39 MB
Description 128-MBit Synchronous DRAM
Datasheet download datasheet HYB39S128160FE Datasheet
Additional preview pages of the HYB39S128160FE datasheet.
