RF2302 Datasheet - RF Micro Devices

BROADBAND LINEAR VARIABLE GAIN AMPLIFIER

RF2302 General Description

The RF2302 is a broadband linear variable gain amplifier that was designed specifically for digital communications systems that require linear amplification over a wide gain control range. It is suitable for use in CDMA or TDMA systems in the cellular or PCS band, in DAMPS systems, and in PDC syste.

RF2302 Datasheet (162.72 KB)

RF2302 Datasheet Preview — Preview of RF2302 PDF

Datasheet Details

Part number:

RF2302

Manufacturer:

RF Micro Devices

File Size:

162.72 KB

Description:

Broadband linear variable gain amplifier.
RF2302 4 BROADBAND LINEAR VARIABLE GAIN AMPLIFIER Typical Applications CDMA Cellular/PCS and JCDMA Systems Wireless Local Loop S.
