EL7182 Datasheet, Driver, Renesas

EL7182 Features

• Driver
• 3V and 5V Input compatible
• Clocking speeds up to 10MHz
• Reduced clock skew
• 20ns Switching/delay time
• 2A Peak drive
• Low quiesce

PDF File Details

Part number:

EL7182

Manufacturer:

Renesas ↗

File Size:

496.55kb

Download:

📄 Datasheet

Description:

High speed ccd driver. TEST CONDITIONS INPUT VIH IIH VIL IIL VHVS OUTPUT Logic “1” Input Voltage Logic “1” Input Current Logic “0” Input Voltage Logic “

EL7182 Application

• Applications as in color fax machines. The input is TTL and 3V compatible. The low quiescent current requirement is advantageous in portable/batter
