HD74BC540A Datasheet, Drivers, Renesas

HD74BC540A Features

• Drivers low power dissipation that is about 1/5 of high speed bipolar logic IC, when the frequency is 10 MHz. The device has eight inverter drivers with three state outputs in a 20 pin package.

PDF File Details

Part number:

HD74BC540A

Manufacturer:

Renesas ↗

File Size:

191.33kb

Download:

📄 Datasheet

Description:

Octal buffers/line drivers. The HD74BC540A provides high drivability and operation equal to or better than high speed bipolar standard logic IC by using Bi-CMOS
