IDT72V3666, IDT72V3656 - CMOS TRIPLE BUS SyncFIFO

Name: IDT72V3666
SKU: IDT72V3666-1492999

Renesas

📥 Download Datasheet

IDT72V3666 Datasheet Preview — This datasheet PDF includes multiple part numbers: IDT72V3666, IDT72V3656. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	IDT72V3666, IDT72V3656
Manufacturer	Renesas
File Size	829.46 KB
Description	CMOS TRIPLE BUS SyncFIFO
Datasheet	IDT72V3656-Renesas.pdf
Note	This datasheet PDF includes multiple part numbers: IDT72V3666, IDT72V3656. Please refer to the document for exact specifications by model.

IDT72V3666 Product details

Description

The IDT72V3656/72V3666/72V3676 are pin and functionally compatible versions of the IDT723626/723636/723646, designed to run off a 3.3V supply for exceptionally low-power consumption.

Features

Serial or parallel programming of partial flags.
Memory storage capacity: IDT72V3656.
2,048 x 36 x 2.
Big- or Little-Endian format for word and byte bus sizes.
Loopback mode on Port A IDT72V3666.
4,096 x 36 x 2.
Retransmit Capability IDT72V3676.
8,192 x 36 x 2.
Master Reset clears data and configures FIFO, Partial Reset.
Clock frequencies up to 100 MHz (6.5ns access time).
Two independent.
