2SD2153 - High gain amplifier transistor

Product Overview

Rohm

Part number	2SD2153
Manufacturer	ROHM
File Size	50.46 KB
Description	High gain amplifier transistor
Datasheet	2SD2153 Datasheet
Additional preview pages of the 2SD2153 datasheet.

1) Low saturation voltage, typically VCE(sat) = 0.12V at IC = IB = 1A / 20mA 2) Excellent DC current gain characteristics. !External dimensions (Units : mm) 4.0 1.0 2.5 0.5 1.5 0.4 (1) 3.0 0.5 (3) 4.5 1.6 (2) (1) Base (2) Collector (3) Emitter 1.5 0.4 ROHM : MPT3 EIAJ : SC-62 !Absolute maximum ratings (Ta=25°C) Parameter Collector-base voltage Collector-emitter voltage Emitter-base voltage Collector current Collector power dissipation Junction temperature Storage temperature ∗ Single.
