11HS Datasheet (SEMTECH) - Silicon Epitaxial Planar Zener Diodes

11HS, Silicon Epitaxial Planar Zener Diodes

HS Series Silicon Epitaxial Planar Zener Diodes Max.

0.5 Max.

1.9 Min.

27.5 Black Cathode Band Black Part No.

Black "ST" Brand XXX ST Max.

3.9 Min.

27.5 Glass Case DO-35 Dimensions in mm HAbsolute Maximum Ratings (Ta = 25 OC) Parameter Symbol Value Power Dissipation Ptot 500 1) CJunction Temperature Tj 175 Storage Temperature Range Tstg - 55 to + 175 E1) Valid provided that leads are kept at ambient temperature at a distance of 8 mm from case.

Unit mW OC OC TCharacteristics a
