11HSB, 11HS Datasheet - SEMTECH

11HSB Silicon Epitaxial Planar Zener Diodes

HS Series Silicon Epitaxial Planar Zener Diodes Max. 0.5 Max. 1.9 Min. 27.5 Black Cathode Band Black Part No. Black "ST" Brand XXX ST Max. 3.9 Min. 27.5 Glass Case DO-35 Dimensions in mm HAbsolute Maximum Ratings (Ta = 25 OC) Parameter Symbol Value Power Dissipation Ptot 500 1) CJunction Temperature Tj 175 Storage Temperature Range Tstg - 55 to + 175 E1) Valid provided that leads are kept at ambient temperature at a distance of 8 mm from case. Unit mW OC OC TCharacteristics a.

11HS-SEMTECH.pdf

This datasheet PDF includes multiple part numbers: 11HSB, 11HS. Please refer to the document for exact specifications by model.
11HSB Datasheet Preview Page 2 11HSB Datasheet Preview Page 3

Datasheet Details

Part number:

11HSB, 11HS

Manufacturer:

SEMTECH

File Size:

597.22 KB

Description:

Silicon epitaxial planar zener diodes.

Note:

This datasheet PDF includes multiple part numbers: 11HSB, 11HS.
Please refer to the document for exact specifications by model.
