MMBTA42W NPN Silicon High Voltage Transistors

MMBTA42W NPN Silicon High Voltage Transistors for high voltage switching and amplifier applications. Absolute Maximum Ratings (Ta = 25 OC) Parameter Symbol SOT-323 Plastic Package Value Unit Collector Base Voltage VCBO 300 V Collector Emitter Voltage VCEO 300 V Emitter Base Voltage VEBO 6 V Collector Current Power Dissipation Junction and Storage Temperature Range Characteristics at Ta = 25 OC HParameter DC Current Gain at VCE = 10 V, IC = 1 mA Cat VCE = 10 V, IC = 10 mA at VCE.

MMBTA42W Datasheet (371.45 KB)

MMBTA42W Datasheet Preview — Preview of MMBTA42W PDF

Datasheet Details

Part number:

MMBTA42W

Manufacturer:

SEMTECH

File Size:

371.45 KB

Description:

Npn silicon high voltage transistors.
