GD20FSX65L4S Datasheet - STARPOWER

GD20FSX65L4S - IGBT

GD20FSX65L4S Features

* Low VCE(sat) Trench IGBT technology

* 6μs short circuit capability

* VCE(sat) with positive temperature coefficient

* Maximum junction temperature 175oC

* Low inductance case

* Fast & soft reverse recovery anti-parallel FWD

* Isolated heatsink using DBC technology Typic

Datasheet Details

GD20FSX65L4S

STARPOWER

215.17 KB

Igbt.
