M93S66-W, M93S46-W Datasheet - STMicroelectronics

M93S66-W MICROWIRE bus EEPROM

5 2 Signal description 6 2.1 Serial data output (Q) 6 2.2 Serial data input (D) 6 2.3 Serial clock (C) 6 2.4 Chip select (S) 6 2.5 Protection register (PRE) 6 2.6 Write protect (W) 6 2.7 VSS ground 6 2.8 Supply voltage (VCC) 6 2.8.1 Operating supply voltage VCC 6 2.8.2 Device reset 7 2.8.3 .

M93S66-W Features

* Compatible with MICROWIRE bus serial interface

* Memory array

* 1 Kbit, 2 Kbit or 4 Kbit of EEPROM

* Organized by word (16b)

* Page = 4 words

* Write

* Byte write within 5 ms

* Page write within 5 ms

* Ready/busy signal during
