M93C06 Datasheet - ST Microelectronics

16Kbit / 8Kbit / 4Kbit / 2Kbit / 1Kbit and 256bit 8-bit or 16-bit wide

M93C06 Features

* SUMMARY s s s s s s s s s s s Industry Standard MICROWIRE Bus Single Supply Voltage:

* 4.5 to 5.5V for M93Cx6

* 2.5 to 5.5V for M93Cx6-W

* 1.8 to 5.5V for M93Cx6-R Dual Organization: by Word (x16) or Byte (x8) Programming Instructions that work on: Byte, Word or Entire Mem

M93C06 General Description

These electrically erasable programmable memory (EEPROM) devices are accessed through a Serial Data Input (D) and Serial Data Output (Q) using the MICROWIRE bus protocol. Figure 2. Logic Diagram Table 3. Memory Size versus Organization Device Number of Bits 16384 8192 4096 2048.
