STK32N4LLF5 - Power MOSFET

Product Overview

STMicroelectronics

Datasheet Details

Part number	STK32N4LLF5
Manufacturer	STMicroelectronics
File Size	256.94 KB
Description	Power MOSFET
Datasheet	STK32N4LLF5 Datasheet
Additional preview pages of the STK32N4LLF5 datasheet.

Product details

Description

This product utilizes the 5th generation of design rules of ST’s proprietary STripFET™ technology. Qg, in this chip scale package, makes this device suitable for the most demanding DC-DC converter applications, where high power density is to be achieved.

Features

Type STK32N4LLF5.
VDSS RDS(on) max RDS(on).
Qg 40 V < 0.0025 Ω 106.4nC.
mΩ Ultra low top and bottom junction to case thermal resistance Extremely low on-resistance RDS(on) RDS(on).
Qg industry benchmark High avalanche ruggedness Fully encapsulated die 100% Matte tin finish (in compliance with the 2002/95/EC european directive) PolarPAK® is a trademark of VISHAY Figure 1. Internal schematic diagram PolarPAK®.
