Description

BL0200 series are 2ch output LED driver IC for LED backlight, and it can do dimming to 0.02 % by external PWM signal.

Features

and Benefit Boost convertor.
Current-Mode type PWM Control.
PWM frequency is 100 kHz o r 200 kHz.
Maximum On Duty is 90 % LED current control.
Individual PWM Dimming Control.
Analog Dimming.
High contrast ratio is 1 / 5000.
Accuracy of Reg output voltage is ± 1.5 % or ± 2 % Protection functions.
Enable Function of IC (BL0202B, BL0202C).
Error Signal Output (BL0200C).
Overcurrent Protection for Boost Circuit (OCP) ---------------------------------.
