LB11620GP - Brushless Motor Driver

Product Overview

Sanyo Semicon Device

📥 Download Datasheet

LB11620GP Brushless Motor Driver by Sanyo Semicon Device - Datasheet Preview — Datasheet preview – LB11620GP

Datasheet Details

Part number	LB11620GP
Manufacturer	Sanyo Semicon Device
File Size	189.54 KB
Description	Brushless Motor Driver
Datasheet	LB11620GP Datasheet
Additional preview pages of the LB11620GP datasheet.

Product details

Description

Hall sensor inputs from each motor phase.

Features

Three-phase bipolar drive.
Direct PWM drive (input of either a control voltage or a variable-duty PWM signal).
Built-in forward/reverse switching circuit.
5V regulator output (VREG pin).
Built-in current limiter circuit (0.25V (typical) reference voltage).
Built-in under voltage protection circuit.
Built-in automatic recovery type constraint protection circuit (ON: OFF=1: 18) with protection operating state discrimination output (RD.
