STK7561A - Chopper Type Parallel 2-Output Voltage Regulators

📥 Download Datasheet

Preview of STK7561A PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number STK7561A
Manufacturer Sanyo Semicon Device
File Size 516.90 KB
Description Chopper Type Parallel 2-Output Voltage Regulators
Datasheet download datasheet STK7561A-SanyoSemiconDevice.pdf

STK7561A Product details

Description

of Operation of Internal Blocks [OSC] External excitation type OSC circuit where the CMOS NAND gate-used ring OSC is formed by the 2-stage NAND circuit, delivering basic pulses.This circuit provides pulse width modulation where the frequency is constant and the duty only varies.[PWM] Pulse width modulation (PWM) is provided by differentiating the output of NAND gate 2 using the differentiating circuit of time constant CR as shown left and by applying the result to the input of NAND gate 3. Th

Features
