STT6602 MOSFET

The STT6602 uses advanced trench technology to provide excellent on-resistance and low gate charge. The complementary MOSFETs form a high-speed power inverter, suitable for a multitude of applications. The TSOP-6 package is universally used for all commercial-industrial surface mount applications. A.

STT6602 Features

* Low Gate Change Low On-resistance 1 2 3 F DG K C H J MARKING REF. 6602 Date Code A B C D E F Millimeter Min. Max. 2.70 3.10 2.60 3.00 1.40 1.80 1.10 MAX. 1.90 REF. 0.30 0.50 REF. G H J K L Millimeter Min. Max. 0 0.10 0.60 REF. 0.12 REF. 0° 10° 0.95 REF. PACKAGE INFORMATION Package TSOP-
