IP1524B - REGULATING PULSE WIDTH MODULATORS

Seme LAB

Datasheet Details

The IP1524B is a pulse width modulator for switching power supplies which

Pin Compatible with IP1524 Series 7 to 40 volt operation 5 volt reference trimmed to ±1% Undervoltage lockout Excellent external sync capability Wide current limit common mode range +5 Volt error amplifier common mode PWM data latch Full double-pulse suppression logic 50ns shutdown function Dual 200mA, 60V output transistors Fully specified over temperature J Package.
