2SC4980 Switching Power Transistor

SHINDENGEN Switching Power Transistor HSV Series 2SC4980 (TP5S8) 5A NPN OUTLINE DIMENSIONS Case : ITO-220 Unit : mm RATINGS œAbsolute Maximum Ratings Item Symbol Conditions Ratings Unit Storage TemperatureTstg -55 `150 Ž Junction Temperature Tj 150 Ž Collector to Base Voltage V 100 V CBO Collector to Emitter Voltage V 80 V CEO Emitter to Base Voltage V 7 V EBO Collector Current DC I 5 A C Collector Current Peak I 10 A CP Base Current DC I 1.5 A B Base Curre.
