Q62702-A1105 Datasheet - Siemens Semiconductor Group

Q62702-A1105 Silicon Schottky Diodes

BAT 63-099R Silicon Schottky Diodes Zero bias diode array for mixer and detectors up to GHz frequencies Crossover ring quad Type Marking Ordering Code Q62702-A1105 Pin Configuration 1=A 2=C Package SOT-143 BAT 63-099RSN Maximum Ratings Parameter Diode reverse voltage Forward current Total power dissipation, BAT17W Junction temperature Operating temperature range Storage temperature Symbol Values 40 40 Unit V mA mW 150 - 55 + 150 °C VR IF TA ≤ 97°C Ptot Tj Top Tstg T.

Q62702-A1105_SiemensSemiconductorGroup.pdf

Q62702-A1105 Datasheet Preview — Preview of Q62702-A1105 PDF

Datasheet Details

Part number:

Q62702-A1105

Manufacturer:

Siemens Semiconductor Group

File Size:

87.53 KB

Description:

Silicon schottky diodes.
