SY7070 Datasheet, Boost, Silergy

SY7070 Features

• Boost
• 0.7V Minimum input voltage
• 5.5uA typical quiescent current
• Input under-voltage lockout
• Bypass function during shutdown
• Low RDS(ON) (mai

PDF File Details

Part number:

SY7070

Manufacturer:

Silergy

File Size:

923.94kb

Download:

📄 Datasheet

Description:

100ma maximum output current synchronous boost. SY7070/A is a high efficiency, synchronous, current hysteresis control; step-up boost converter designed for single-cell or dual-cell

SY7070 Application

• Applications It can convert down to 0.7V input voltage. It adopts NMOS for the main switch and PMOS for the synchronous switch. Ordering Informatio
