SPF-2000 Datasheet, Fet, Sirenza Microdevices

SPF-2000 Features

• Fet
• 15 dB Gmax at 12GHz
• 1.25 dB FMIN at 12 GHz
• +32 dBm Output IP3 at 12GHz
• +20 dBm Output Power at 1dB Compression Applications
• High IP3 LN

PDF File Details

Part number:

SPF-2000

Manufacturer:

Sirenza Microdevices

File Size:

284.09kb

Download:

📄 Datasheet

Description:

Low noise high linearity phemt gaas fet. Sirenza Microdevices’ SPF-2000 is a high linearity, low noise 0.25µm pHEMT. This 300µm device is ideally biased at 3V,20mA for lowest

SPF-2000 Application

• Applications Low Noise High Linearity pHEMT GaAs FET 0.1 - 12 GHz Operation Typical Gain Performance 30 25 20 Gmax 3V, 20mA 5V, 40mA Gain, Gmax
