B-13-15-155-T3-SSC4 Datasheet, Transceiver, Source Photonics

B-13-15-155-T3-SSC4 Features

• Transceiver
• Diplexer Single mode, Single Fiber 1x9 SC Receptacle Connetor
• Wavelength Tx 1310nm/Rx 1550 nm
• SONET OC-3 SDH STM-1 Compliant
• Single +5V Power Sup

PDF File Details

Part number:

B-13-15-155-T3-SSC4

Manufacturer:

Source Photonics

File Size:

916.98kb

Download:

📄 Datasheet

Description:

155 mbps bi-directional sc receptacle single fiber transceiver.

B-13-15-155-T3-SSC4 Application

• Applications assistance, customer product design, software performance, or infringement of patents, services, or intellectual property described her
