TK11812

DC-DC CONVERTER

TK11812 Features

* s s s s s Miniature Package (SOT-23L) Low Start-up Voltage [0.6 V (typ.)] Few External Components Adjustable Output Voltage (1.5 to 15 V) Wide Input Voltage Range (0.6 to 14 V) APPLICATIONS s s s s s s s s Pagers Cassette Recorders Cordless Telephones Portable Instrumentation Radio Control Systems

TK11812 General Description

The TK11812 is a low power, low input voltage step-up DC-DC converter. This device can be set to an output of 1.5 to 15 V DC using two resistors. The output current is dependent upon the input voltage and ranges from 8 mA at 1.6 V to 24 mA at 3.5 V. The efficiency is over 80% for an output current o.

TK11812 Datasheet (53.98 KB)

Preview of TK11812 PDF

Datasheet Details

Part number:

TK11812

Manufacturer:

TOKO

File Size:

53.98 KB

Description:

Dc-dc converter.
