2SK1381 Datasheet - Toshiba Semiconductor

2SK1381 Silicon N-Channel MOSFET

2SK1381 TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (L2 π MOSIII) 2SK1381 Relay Drive, Motor Drive and DC DC Converter Applications Unit: mm z 4-V gate drive z Low drain source ON-resistance : RDS (ON) = 25 mΩ (typ.) z High forward transfer admittance : |Yfs| = 33 S (typ.) z Low leakage current : IDSS = 100 μA (max) (VDS = 100 V) z Enhancement mode : Vth = 0.8 to 2.0 V (VDS = 10 V, ID = 1 mA) Absolute Maximum Ratings (Ta = 25°C) Characteri.

2SK1381 Features

* noncompliance with applicable laws and regulations. 6 2009-12-10

2SK1381_ToshibaSemiconductor.pdf

Preview of 2SK1381 PDF
2SK1381 Datasheet Preview Page 2 2SK1381 Datasheet Preview Page 3

Datasheet Details

Part number:

2SK1381

Manufacturer:

Toshiba ↗ Semiconductor

File Size:

405.56 KB

Description:

Silicon n-channel mosfet.
