TB62206FG - BiCD PWM 2-Phase Bipolar Stepping Motor Driver

Product Overview

Toshiba Semiconductor

Part number	TB62206FG
Manufacturer	Toshiba Semiconductor
File Size	1.02 MB
Description	BiCD PWM 2-Phase Bipolar Stepping Motor Driver
Datasheet	TB62206FG Datasheet
Additional preview pages of the TB62206FG datasheet.

Bipolar stepping motor driver IC.
Internal PWM current control.
2.
phase/1.
2 phase excitation is available.
Monolithic BiCD IC DMOS FET used for output power transistor Weight: 0.79 g (typ. ).
High voltage output and High current: 40 V/1.8 A (max).
On.
chip thermal shutdown circuit, overcurrent protection circuit and power.
on reset circuit (POR).
Package: HSOP20.
P.
450.
1.00.
