TC74AC112FN - Dual J-K Flip-Flop

www.DataSheet4U.com TC74AC112P/F/FN TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic TC74AC112P,TC74AC112F,TC74AC112FN Dual J-K Flip Flop with Preset and Clear Note: The TC74AC112 is an advanced high speed CMOS DUAL J-K FLIP FLOP fabricated with silicon gate and double-layer metal wiring C2MOS technology. It achieves the high speed operation similar to equivalent Bipolar Schottky TTL while maintaining the CMOS low power dissipation. In accordance with the logic level given J and K i.

TC74AC112FN Features

* High speed: fmax = 170 MHz (typ.) at VCC = 5 V Low power dissipation: ICC = 4 µA (max) at Ta = 25°C High noise immunity: VNIH = VNIL = 28% VCC (min) Symmetrical output impedance: |IOH| = IOL = 24 mA (min) Capability of driving 50 Ω DataShee
