TC74ACT138FN 3 - TO - 8 LINE DECODER

TC74ACT138P/F/FN/FT TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic TC74ACT138P,TC74ACT138F,TC74ACT138FN,TC74ACT138FT 3-to-8 Line Decoder The TC74ACT138 is an advanced high speed CMOS 3-to-8 LINE DECODER fabricated with silicon gate and double-layer metal wiring C2MOS technology. It achieves the high speed operation similar to equivalent Bipolar Schottky TTL while maintaining the CMOS low power dissipation. This device may be used as a level converter for interfacing TTL or NMOS to H.

TC74ACT138FN Features

* High speed: tpd = 6.0 ns (typ.) at VCC = 5 V

* Low power dissipation: ICC = 8 μA (max) at Ta = 25°C

* Compatible with TTL outputs: VIL = 0.8 V (max) VIH = 2.0 V (min)

* Symmetrical output impedance: |IOH| = IOL = 24 mA (min) Capability of driving 50 Ω transmission l

TC74ACT138FN Datasheet (254.97 KB)

TC74ACT138FN Datasheet Preview — Preview of TC74ACT138FN PDF

Datasheet Details

Part number:

TC74ACT138FN

Manufacturer:

Toshiba ↗ Semiconductor

File Size:

254.97 KB

Description:

3 - to - 8 line decoder.
