SILICON NPN TRIPLE DIFFUSED TYPE
SWITCHING REGULATOR AND HIGH VOLTAGE SWITCHING APPLICATIONS. HIGH SPEED DC-DC CONVERTER APPLICATION.
FEATURES . Excellent Switching Times
t r=1.0As(Max.), tf=1.0/is(Max.) at Ic=0.8A . High Collector Breakdown Voltage : VcEO= 400V
INDUSTRIAL APPLICATIONS Unit in mm
10.3 MAX .
MAXIMUM RATINGS (Ta=25°C)
CHARACTERISTIC
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Base Current
Collector Power Dissipation
Ta=25 C Tc=25 C
SYMBOL VcBO VCEO VEBO
IB
PC
RATING 500 400
0.5 1.7
20
UNIT
1. BASE 2.
2SC3235 Datasheet
