TA76432AS - 1.26V Adjustable High-Precision Shunt Regulators

Product Overview

Toshiba

Part number	TA76432AS
Manufacturer	Toshiba
File Size	303.25 KB
Description	1.26V Adjustable High-Precision Shunt Regulators
Datasheet	TA76432AS Datasheet
Note	This datasheet PDF includes multiple part numbers: TA76432AS, TA76432AFT. Please refer to the document for exact specifications by model.
Additional preview pages of the TA76432AS datasheet.

Precision reference voltage: VREF = 1.26 V ± 1% (Ta = 25°C).
Small temperature coefficient: |αVREF| = 30 ppm/°C (typ. ).
Adjustable output voltage: VREF ≤ VOUT ≤ 19 V.
Minimum cathode current for regulation: Ikmin = 0.5 mA (max. ).
Operating temperature: Ta =.
40 to 85°C.
The TA76432AFT is housed in an ultra-thin UFV package. (thickness: 0.7 mm typ. ).
Packages: UFV (TA76432AFT), PW-Mini (TA76432AF/AFR) and LSTM (TA76432AS) TA.
