TD62064BF Datasheet, Driver, Toshiba

TD62064BF Features

• Driver Package Type BP
• 1 : DIP16 pin BF : HSOP16 pin High Output Sustaining Voltage : VCE(SUS) = 80 V (min) Output Current (Single Output) : IOUT = 1.5 A / ch (max) Output Clamp Diodes

PDF File Details

Part number:

TD62064BF

Manufacturer:

Toshiba ↗

File Size:

413.80kb

Download:

📄 Datasheet

Description:

4ch high-current darlington sink driver.

TD62064BF Application

• Applications include relay, hammer, lamp and stepping motor drivers. FEATURES Package Type BP
• 1 : DIP16 pin BF : HSOP16 pin High Output Sust
