TPD7104F 1-channel High-Side N channel Power MOSFET Gate Driver

Pin No. 1 2 3 4 5 6 7 8 Symbol Function. VDD IS OUT GND GND IN DIAG RISref Power supply pin. Detection pin for over current. If overcurrent detection is not used, IS pin connect to GND. Output pin. State is off if detect overcurrent. Ground pin. Ground pin. Input pin. IN has a pull-down resisto.

TPD7104F Features

* Charge pump circuit is built in

* Over current protection circuit is built in

* Housed in the PS-8 package and supplied in embossed carrier tape Pin Assignment (top view) 1 VDD 2 IS 8 RISref 7 DIAG 3 OUT 6 IN 4 GND 5 GND Note: 4pin and 5pin should short-circuit externally. SON
